Non-Standard Case Dimension
Machine can be modified for a variety of case dimensions. Please contact Lantech for details.
Various communication configurations possible. Please contact Lantech for details.
Stainless Steel Frame or Components
Please contact Lantech for details.
Exit Height Extension
The exit height can be extended.
Tape Head Storage Bracket
Holds additional tape head.
75mm (3") Tape Head
Applies 3" wide tape. Replaces standard 2" tape head.
Many options available for case types and dimensions, speeds, closing methods, machine frame and magazine, and machine performance data communications are available. Please contact Lantech Customer Support if your requirements are not satisfied by the options published on this page.
An alarm sounds to indicate the presence of a fault condition.
Precison Hot Melt Nozzels
High efficiency nozzles spray hot melt exactly where you want it.
Welded steel frame and heavy duty locking casters provide easy maneuverability.
Separation Module with Infeed Guiding
Separation cylinders on the infeed to ensure a gap of min 350 mm (13 4/5") between cases.
Colored lights indicate the status of the machine, blanks supply, and tape or hot melt supply.
Up to 30 Cases/Minute
(Depending on Case Dimensions)
Case Size Minimum
(Outside Dimensions) 200 mm L
150 mm W
120 mm H
(7 7/8" L x 5 7/8" W x 4 3/4" H)
Case Size Maximum
(Outside Dimensions) 650 mm L
510 mm W
500 mm H
(25 5/8" L x 20 1/8" W x 19 5/8" H)
Tape Lantech TH- Series
Hot Melt OptionalService Requirements
Air Supply 6 Bar (80 Psi)
Dedicated Electric Service Req. US 230V, 3ph, 60 Hz, Wye w/Ground
Dedicated Electric Service Req. EU 3L-PE-400V-50 Hz-NeutralMachine Data
1830 mm L
1120 mm W
1800 mm H
(72" L x 44" W x 70 7/8" H)
Warranty Duration 3 Years, Unlimited Cycles
