Lantech SL400 Stretch Wrappers

Home » Products » Rotary Arm » SL400

Lantech’s simple automation solution for warehouse environments

Ideal for very light, very heavy or very unstable loads
Load doesn’t rotate
No conveyors or ramps required
No weight limitations
No scheduled preventative maintenance

Download leaflet

Get a Quote

Ideal for warehouse environments with little-to-no automation

Load Guardian^® removes the operator guesswork required to wrap a good, quality load at the lowest cost
Standard safety features include large safety shield for wrap zone, wrap cycle alarms and beacons, and control panel mounted at the rear, away from the wrap zone
3 Year warranty – no exclusions, unlimited cycles, no exceptions

Available Options

Extended Wrap Height
Increase the wrap heights of your loads. Replace the 2032 mm (80") mast with a 2794 cm (110") mast.

TurboTak®
NEW! Eliminate dragging film tails. Compact, robust design was made to survive warehouse environments, and does not require heat.

Specifications

Performance

Peak Production Speed

Up to 40 Loads/Hr

Load Size Diagonal (Recommended)

1931 mm (76")

Maximum Load Wrap Height

2032 mm (80")

Maximum Load Weight

Floor capacity

Performance Features

XT Cut and Clamp 5.0®

Not available

Auto Film Cut-Off®

Standard

Pallet Grip®

Standard

Intelli-Sensor

Standard

Load Guardian

Standard

Standard Film Width

500 mm (20")

EZ Thread Film Delivery

Standard

Standard Pre-Stretch

225%

Wrap Force

Variable (Electric)

Film Capacity

250 mm Diameter, 500 mm Length (10” Diameter, 20” Length)

Film Delivery System

Power Roller Stretch Plus

NEMA Type 1 Enclosure

Standard

TurboTak®

Optional

Load Handling

Wrap Arm Drive

3/4 HP TEFC

Wrap Arm Speed

15 RPM

Wrap Arm Zone

2280 mm (90")

Weight and Size

Approx. Shipping Weight

1361 kg (3000 lbs)

Size

4801 mm L x 3810 mm W x 3073 mm H
(189" L X 150" W X 121" H)

Service Requirements

Pneumatic

Not Applicable

Dedicated Electric Service Required

240VAC/20A/1-Phase/50-60Hz

Warranty

Warranty Duration

3 Years, Unlimited Cycles, All Components Covered

Load Guardian®

Load Guardian is Lantech’s patented control system that is based on 50+ years of customer observations. It eliminates the operator guesswork to make it simple to create, maintain and deliver the right containment force for safe-to-ship loads every time.

Creates

Load Guardian creates and saves profiles.

Intuitively guides users through the profile creation process, using recognizable icons and smartphone-like simplicity, to calculate the right containment force.
Eliminates the consequences that can occur when an operator has to make 12 or more decisions to stretch wrap a load.

Maintains

Load Guardian maintains profile standards automatically.

Eliminates or minimizes routine operator touches and tweaks with single tap profile selection.
Eliminates the consequences that can occur when an operator has to make 12 or more decisions to stretch wrap a load.

Delivers

Load Guardian delivers the right amount of containment force.

Provides a knowable, repeatable cost per load.
Eliminates the consequences that can occur when an operator has to make 12 or more decisions to stretch wrap a load.

TurboTak® option for the SL400

TurboTak’s patented design eliminates dragging film tails by providing two stages of precise, high-velocity blasts of air: The first blast shapes the film web in the precise location; the second, more focused blast, “nails” the film tail to the underlying layers of film.
