6,000 LB Capacity Turntable
6,000 lb capacity for Lantech supplied base system. Available in 5' sections and 10' and 12' wrap zone sections. 3" diameter rollers on 3-3/4" centers.
Cold Package option allows efficient operation of stretch wrapper in an environment where the temperature range is -1 to -13 degrees Celsius (+31 to +10 degrees Fahrenheit).
750 MM Metered Film Delivery System
For customer applications where 30” wide film is used.
25 RPM Package
Wrap arm rotation is increased to 25 rpm. Includes additional fencing, visual barriers (Yellow Railroad Gates) at the infeed and exit transition, and a larger machine frame.
35 RPM Package
Wrap arm rotation is increased to 35 rpm. Includes additional fencing, visual barriers (Yellow Railroad Gates) at the infeed and exit transition, and a larger machine frame.
40 RPM Package
Wrap arm rotation is increased to 40 RPM. Includes 9/5/9 standard spaced conveyor layout with variable speed drive control and conveyor speeds of 60-90 FPM (high speed staging). Includes additional fencing and safety light guards.
Top Sheet Dispenser
Two to four mil poly film, 80" wide is automatically applied over the top of load for moisture and dust protection. In-line top sheet dispenser model applies and secures sheet of film over load as it indexes into the wrap zone with no interruption to the wrapping cycle. Mid-wrap top sheet dispenser applies and secures sheet of film over top of load during the wrapping cycle. Load is protected with five-sided coverage.
Available in 5' sections and 10' and 12' wrap zone sections. Close-spaced and tight-spaced conveyor rollers. Standard and non-standard pass heights. Includes safety fencing and additional safety photocells mounted on the safety shield.
Additional Wrap Height Capacity
For wrapping loads which exceed the 2032 mm (80") wrap height capacity of the standard system. Will handle loads up to 2794 mm (110") tall. Increases total operating height to 5486 mm (216") at standard pass height.
Production Speed 45 - 50 Loads/Hr
Maximum Load Size
1473 mm L
1473 mm W
1905 mm H
(58" L X 58" W X 75" H)
Minimum Load Size
914 mm L
914 mm W
686 mm H
(36"L x 36"W x 27"H)
Maximum Load Weight Conveyor CapacityLoad Handling
Wrap Arm Drive DC Drive Motor Control
Wrap Arm Speed 1- 15 RPMPerfomance Features
Pallet Grip® Standard
Load Guardian N/A
Standard Pre-Stretch 250% (100-300% Available)
254 mm Diameter, 508 mm Width
(10"D x 20" W)
Film Delivery System Power Roller-Stretch
Automation Unit - Film Clamp Load Seeking Clamp® and Reach Arm with Pulsed Hot WireWeight and Size
Approx. Shipping Weight
Pneumatic 85-142 lpm @ 6 Bar, 3-5 cfm @ 80 Psi Clean, Dry Air
Dedicated Electric Service Req. US 480V, 3ph, 60Hz, Wye w/Ground
Dedicated Electric Service Req. EU 3L-PE-400V-50Hz (No Neutral)
Enclosure NEMA 12 with Disconnect and Safety Lock-out
Control PLC with HMIWarranty
Warranty Duration 3 Years, Unlimited Cycles
